Manufacturer:
Tektronix
Quantity:1
Location:
Electronic Work Bench Area
Operational *
Overview
Instrument that graphically displays electrical signals and shows how those signals change over time.
Technical Details
|
Four-channel, 100 MHz, 1.25 GS/s digital phosphor oscilloscope with a TFT color screen.
Access & Hazard Information
Standard Access
Members are allowed to use this equipment. Access rules are defined by the equipment’s hazard class. Read the hazard class descriptions.
Hazard Class 1
- Hazards:Minor injuries that can be resolved with first aid kit or ice pack
- Power:Less than 0.25 HP, 2-4 amps, 120 VAC or up to 18V DC
- Examples: Lower power hand tools and small bench tools. Drills, glue guns, soldering tools, heat guns, 3D printers, 3D scanner
- Access Requirements: Members must attend a training session and pass written and hands-on exams. Improper use will be punished with a verbal warning.
- Supervision Requirements: The Makerspace must be open and a makerspace staff member must be present in the facility.
